Control4® Square Wired Configurable Keypad — C4-SKCB2-N

The Control4® Square Wired Configurable Keypad V2 combines beautiful aesthetics and flexible button configuration, providing a stunning user interface that elegantly controls any aspect of a Control4® system. Control lights, scenes, music, security—the possibilities are endless. The keypad can be configured with two to seven buttons using five different button sizes for a total of 38 possible configurations. There’s no need to worry about how many buttons will be needed on a specific keypad prior to (or even after) installation.

• Elegant, sophisticated design makes a beautiful addition to any home or business.

• Custom engraving available to clearly identify each button.

• Backlit buttons with programmable color control for easy readability regardless of time of day or light level.

• Programmable RGB LEDs provide status feedback for lighting and other devices in the system.

• Ambient light sensor automatically adjusts backlight and status LED brightness depending on the light level in the room.

• Ships as "neutral" device with no buttons included. Keypad-style button kit and rocker-style button kits sold separately in a variety of colors (see "Available accessories").

• Control4® screw-less faceplates, sold separately, provide a sleek profile (see "Available accessories").

• RS-485 Bus Communication.

• Requires 48V Bus Power Supply and Bus Ethernet Gateway.

• Installs in standard square (UK/China-style) or round (EU-style) wall boxes. Round (EU-style) wall boxes require trim ring (see "Available accessories").
