Sonance IS10 - Invisible Series Speaker /st
Kontakta oss för frågor eller köp!
Sonance Invisible Series Speakers Featuring Motion Flex Technology
Sonance Invisible Series
KEY FEATURES
MOTION FLEX TECHNOLOGY
A suite of advancements in invisible speaker engineering for unparalleled acoustic performance from an invisible speaker
WAVE FLEX DRIVE UNIT
High-bandwidth midrange and high-frequency transducer that leverage the bending-wave principle, delivering velvety-smooth mids and crystal-clear highs
AIR FLEX WOOFER
Glass-fiber woofer coupled to an acoustically inert diaphragm to move a pocket of air like a piston for robust and powerful bass
ACOUSTICALLY ISOLATED BAFFLE
The diaphragm is split into two active areas that are completely isolated to enable ultra-low distortion sonic transparency like never before
CONSTANT DIRECTIVITY CROSSOVER (CDX)
The proprietary Sonance CDX provides uniquely smooth off-axis frequency response for greater fidelity and coverage and almost 180° of horizontal and vertical dispersion
SONANCE DEPTH IDENIFICATION SENSING CALIBRATION (DISC) SYSTEM
Uses a high-accuracy depth gauge and embedded locator discs to measure the thickness of a finish applied over the surface of a Sonance Invisible Speaker, allowing for a consistent finish and performance within specifications every time
Specifications - IS10
SKU: 93480
Wave Flex Drive Unit: 29in² (188cm²) bending wave diaphragm 1.75" (44mm) voice coil
Air Flex Woofer: 244in² (1573cm²) air pulse diaphragm 10" (254mm) carbon fiber woofer
Frequency Response: 35Hz–30kHz (±3dB)
Impedance: 6 Ohms Nominal
Power Handling (RMS): 200W
Sensitivity (2.83V/1m): 87dB
Transformer: —
Transformer Taps: —
Overload Protection: —
Dispersion: 170º hemispherical up to 10kHz
Dims (WxHxD): 16.10" x 28.66" x 3.15" (409mm x 728mm x 80mm)
Mounting Depth: 2.68" (68mm)
Back Dims (WxH): —
Product Weight: 18.85 lbs (8.55 kgs)
Shipping Weight: 47.38 lbs (21.49 kgs)
Compatible Space Saver: IS-SAVER-L, SKU 93494
Compatible Enclosure: IS-ENCL-L, SKU 93490
Modell
IS10 - Invisible Series Speaker /stArtikelnummer
2434_93480Varumärke
Jämför produkt
Modellbeskrivning | |
---|---|
Modell
|
IS10 |
Typ av produkt
|
In-wall högtalare |
Aktiv/passiv modell
|
Passiv |
